Rated speed: 1500rpm
| Engine model | 4DW81-23D | 4DW91-29D | 4DW92-35D | 4DW93-42D |
| Type | 4-cylinder 4-stroke | |||
| Air intake type | Natural | Natural | Turbocharged | Turbo& intercool |
| Cooling mode | Water cooling | |||
| Governor mode | Mechanical& electronic | |||
| Bore×Stroke(mm） | 85×100 | 90×100 | ||
| Compression ratio | 18.5:1 | |||
| Rated speed(rpm) | 1500 | |||
| Displacement(L) | 2.27 | 2.54 | ||
| Rated power(without fan)(kW) | 17 | 21 | 26 | 31 |
| Standby power(without fan)(kW) | 19 | 23 | 29 | 34 |
| Fuel consumption(g/kWh) | 240 | 240 | 230 | 216 |
| Oil consumption(L/h) | 0.05 | 0.05 | 0.04 | 0.04 |
| Steady state speed regulation(%) | ≤5 | ≤5 | ≤5 | ≤5 |
| Oil capacity including filter(L) | 7.8 | 8 | 8 | 8 |
| Emission compliant | StageⅡ | |||
| The flywheel shell interface | SAE4 | |||
| Flywheel for 7.5″& 10″flexible coupling | ||||
| Dry weight of base(kg) | 220 | 220 | 240 | 240 |
| Dry weight of Gen Pac(kg) | 240 | 240 | 260 | 280 |
| Overall dimension(base)(mm) | 750×555×680 | 750×555×680 | 750×600×735 | |
| Overall dimension(G.P)(mm) | 920×610×760 | 1120×810×760 | ||
| Fan consumption（kW） | 1.2 | 1.6 | 1.8 | 2 |
| 27℃ air consumption（m3/min） | 1.4 | 1.7 | 2.1 | 2.4 |
| Heat rejection of exhaust（kW） | 17.2 | 17.4 | 20.6 | 23.1 |
| Exhaust gas temperature after turbine（℃） | 550 | 450 | 450 | 450 |
| Exhaust gas flow（m3/min） | 4.2 | 4.6 | 5.9 | 6.7 |
| Heat rejection from engine（kW） | 1.1 | 1.3 | 1.6 | 1.9 |
| Heat rejection of coolant（kW） | 11 | 13.7 | 16.9 | 17.1 |
| Base configuration | Standard configuration(add on the base) | |||
| Engine with fan | Intake and exhaust sysytem: Air filter and connecting pipes; Connecting flang of exhaust pipe | |||
| Alternator 500W 14V Starter motor 3.5kW 12V | Cooling system: Radiator with connecting pipes; Fan guard; Belt guard | |||
Rated speed: 1800rpm
| Engine model | 4DW81-28D | 4DW91-38D | 4DW92-42D | 4DW93-50D |
| Type | 4-cylinder 4-stroke | |||
| Air intake type | Natural | Natural | Turbocharged | Turbo& intercool |
| Cooling mode | Water cooling | |||
| Governor mode | Mechanical or electronic | |||
| Bore×Stroke(mm） | 85×100 | 90×100 | ||
| Compression ratio | 18.5:1 | |||
| Rated speed(rpm) | 1800 | |||
| Displacement(L) | 2.27 | 2.54 | ||
| Rated power(without fan)(kW) | 20 | 28 | 31 | 37 |
| Standby power(without fan)(kW) | 22 | 31 | 34 | 41 |
| Fuel consumption(g/kWh) | 240 | 240 | 230 | 216 |
| Oil consumption(L/h) | 0.05 | 0.05 | 0.04 | 0.04 |
| Steady state speed regulation(%) | ≤5 or ≤3 | |||
| Oil capacity including filter(L) | 7.8 | 8 | 8 | 8 |
| Emission compliant | StageⅡ | |||
| The flywheel shell interface | SAE4 | |||
| Flywheel for 7.5″flexible coupling | ||||
| Dry weight of base(kg) | 220 | 220 | 240 | 240 |
| Dry weight of Gen Pac(kg) | 240 | 240 | 260 | 280 |
| Fan consumption（kW） | 2 | 2 | 2 | 2.2 |
| Base configuration | Standard configuration(add on the base) | |||
| Engine with fan | Intake and exhaust sysytem: Air filter and connecting pipes; Connecting flang of exhaust pipe | |||
| Alternator 500W 14V Starter motor 3.5kW 12V | Cooling system: Radiator with connecting pipes; Fan guard; Belt guard | |||
